High Q High power RF SMD chip capacitor manufacturer from China Shanghai Imax Electronic Co., Ltd.

Place of Origin:

Shanghai, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Application: RF / Microwave

Type: Ceramic Capacitor

Rated Voltage: 1KV

Package Type: Surface Mount

Capacitance: 8200pf

DC Voltage: 500Vdc to 7000Vdc
RF Voltage: 250Vrms to 5000Vrms
RF Current Rating 12A rms

High Q High power RF SMD chip capacitor

High Q chip ceramic capacitor, high power RF ceramic capacitor, high Q SMD capacitor, high power RF capacitor, high Q chip capacitor, high Q RF capacitor, high power chip capacitor, Microwave RF chip capacitor, Microwave chip capacitor, SMD microwave capacitor, RF/microwave Multilayer Capacitors, High Power High current Multilayer Capacitors, High Temperature High Voltage Multilayer Capacitors, ATC RF capacitor, ATC microwave chip capacitor

Features:

Capacitance Range: 82pF to 10000pF

High Q Low ESR/ESL, low noise, high self-resonance, high reliability

High RF Power

Ultra Stable Performance

Operating Voltages

DC Voltage: 500Vdc to 7000Vdc

RF Voltage: 250Vrms to 5000Vrms

RF Current Rating 12A rms

Available with Encapsulation Option, Chip and Ribbon Lead Configurations

Applications

MRI Coils

HF/RF Power Amplifiers

Plasma Chambers

Antenna Tuning

High Power RF Transmitters

Inductive Heating

Semiconductor Equipment

Rated Voltage: 500V, 1000V, 1KV, 1500V, 2000V, 2KV, 2500V, 3000V, 3KV, 3600V, 5000V, 5KV, 6000V, 6KV, 7000V, 7KV, 7200V

Rated Capacitance: 82pf, 91pf, 100pf, 110pf, 120pf, 130pf, 150pf, 160pf, 180pf, 200pf, 220pf, 240pf, 270pf, 300pf, 330pf, 360pf, 390pf, 430pf, 470pf, 510pf, 560pf, 620pf, 680pf, 820pf, 1000pf, 1200pf, 1500pf, 1800pf, 2000pf, 2200pf, 2700pf, 3000pf, 3300pf, 3900pf, 4300pf, 4700pf, 5000pf, 5100pf, 5600pf, 6200pf, 6800pf, 7200pf, 8200pf, 10000pf
